Guidance for TB40 BOX ON P1.95
Resolution for 500×500 P1.9: 256×256, resolution for your screen 1280×768
Prepare: computer/HDMI Cable/Screen
1. Connection
2pcs main signal cable connect with TB40 2 ports.
HDMI cable connect with computer
2. Go into NOVASTAR LCT software and connect screen well just like your rental panels, sent rcfg file to the screen.
3. Open your cellphone, download VIPLEX HANDY
4. Open your wifi and find the wifi for TB40 and connect.
It will needs you to enter into passwords, pls enter with SN2008@+
5. Open your VIPLEX HANDY, click “add device”, it will show as the TB40 you connected, it might need you to enter with passwords again, just forget about it.
6. Click “try now”-enter into the resolution 1280×768-click OK-click “Media” and select video/picture-click “IMPORT”-click “publish”.
